DL205 series
Micromodule Type PLC
KOYO ELECTRONICS INDUSTRIES CO., LTD.
- Five kinds of CPU are available.
- Module addition: Up to 8 slot
- Maximum I/O points: 8,192 points
- Program memory: 2 K to 15.8 K/
Data memory: 2.4 K to 30.4 K
- Communication port: 2 ports
(1 port only for the D2-230)
- PID control: Up to 16 build-in loops (D2-260/265)
Download of DL205e (2.9Mb)
Standard feature
For the DL205, .ve kinds of CPU that have a wide range of power supplies and functions at minimized cost are available. For example, the D2-260 has a total memory of 30.4K (program memory is 15.8K) installed and can support input/output for up to 16,384 points. Moreover, the D2-260 has two built-in communication ports and can be connected to devices such as HMI,serial networks, remote I/O, and ASCII communications. With 260 kinds of instructions, it demonstrates a performance equal to a large, strong control system.The base come sin four sizes, and supports 12/24 V DC and 100/200 V AC as the power source.Moreover, therefore more than 60 models of strong input/output modules and communication modules.
Local input/output for all locations
If the I/O is installed near the user side device, wiring cost can be reduced. Up to four units can be connected in a range of up to 30 m (overall length)from the local side base unit.
Easy maintenance
The DL205 series adopts a stackable con.guration that facilitates module connection and disconnection. If a failure occurs in a module, you can easily restore the system by simply replacing the relevant module.
| URL | http://www.koyoele.co.jp/product/plc/index.html |
|---|---|
| Maximum Program memory Size | 24.0 K |
| Program Memory | EEPROM/FlashMemory/MRAM |
| Maximum I/O points | 8,192 |
Related catalogs
Related catalogs of DL205 series
