Safety PLC
KOSTAC Safety AZ-C1
Safety PLC compatible with international standard safety standards.
KOYO ELECTRONICS INDUSTRIES CO., LTD.
- The KOSTAC Safety AZ-C1 is a safe PLC that meets international safety standards aimed at achieving "zero hazard" via risk assessment.
- The AZ-C1 contains safety relays and safety controllers,and accurately performs supervisory control and monitoring of several devices, while contributing to the simplification of systems.
- As the flexible, low-cost and easy-to-understand "standard of the new age," the AZ-C1 extensively covers from single devices to miniature complex equipment
Download of KOSTAC safety AZC1 (773.7Kb)
Acquired advanced safety certification
The AZ-C1 can be used for applications that meet EN954-1 (category 4),IEC61508 (SIL 3), and ISO13849-1: 2006 (Performance Level e). Users can easily and surely create a safe environment that conforms to international standards.
Unrestricted system expansion via an abundant array of expansion modules.
Many extension modules such as safety control modules and general control modules are available. Their unrestricted mixing and matching makes various system architectures possible, thus meeting a wide range of requirements from easy program-less control to complicated program control.
One-touch installation, one-push wiring
Each module can be attached to the DIN rail, which is widely used as a control panel, with one touch. The use of removable terminal blocks makes wiring operations when replacing devices greatly ef.cient and reduces the risk of malfunctions by wiring errors. You will not need to be troubled with a flood of wiring anymore.
| Program System | Stored program system |
|---|---|
| Program Control System | Cyclic computing system |
| Input-Output Control System | Image register system |
| Execution Tme | 15 ms / Scan |
| Maximum System Reaction Rate:Program-less mode | Only DC output is used. 52.6 ms Relay output is used. 67.6 ms |
| Maximum System Reaction Rate:Programming mode | Only DC output is used. 22.6 ms Relay output is used. 37.9 ms |
| Program Memory | 12 K WORD (Internal memory: 64 KB) |
| Memory Type | CMOS-RAM, FLASH-ROM |
| Backup Battery | Charge type (Lithium battery: Life is up to 5 years ) |
| Display | 7 segments LED×4 |
Related catalogs
Related catalogs of Safety PLC
