Toshiba Teli USB3 Machine Vision Camera BU / DU / DDU Series Catalog

Toshiba Teli’s proud USB3 Machine Vision Camera BU / DU / DDU Series High reliablility & resolution Dual USB3 models 12.3 DDU1207M Series 6.5 DU657M Series MP Sony IMX253 MP Teli Original 16 DDU1607M Series 12.3 DU1207M Series MP OnSemi XGS 16000 MP Sony IMX253 COMING SOON 26.2 DDU2607M Series MP Gpixel GMAX0505 Small & Low resolution Small & Middle resolution 0.4 BU040M Series 3.1 BU302M Series MP Sony IMX287 MP Sony IMX252 1.3 BU132M MP e2v EV76C560 4 BU406M Series MP CMOSIS CMV4000 1.6 BU160M Series MP Sony IMX273 NEW 5 BU502M Series BU505M Series 2 BU205M MP Sony IMX547 Sony IMX250 MP CMOSIS CMV2000 NEW BU238M Series 8 2.3 BU805M Series MP Sony IMX546 MP Sony IMX174 Small & High resolution Rolling shutter models 12.3 BU1207M Series 6.2 BU602M Series MP Sony IMX253 MP Sony IMX178 COMING SOON 12.3 BU1208M Series 12 BU1203M Series MP Sony IMX545 MP Sony IMX226 24.5 BU2409M Series NEW 20 BU2006M Series MP Sony IMX540 MP Sony IMX183 BU Series DU Series DDU Series USB 5Gbps x 2ch USB 5Gbps USB 5Gbps Dual USB3 “Teli Core Technology” “Teli Core Technology” “Teli Core Technology” Inside Inside Inside CMOS Image sensor CMOS Image sensor CMOS Image sensor USB3 Micro B connector USB3 Micro B connector USB3 Micro B connector LED Status indicator LED Status indicator LED Status indicator Round type 6 pin connector e-CON 4 pin connector Trigger input / GPIO Trigger input / GPIO Trigger input / GPIO e-CON 4 pin connector e-CON 4 pin connector Trigger input / GPIO Screw lock Screw lock Screw lock Japanese Design Registration: No. 1462541 https://www.toshiba-teli.co.jp/en/

Toshiba Teli USB3 Camera BU Series / DU Series / DDU Series Featuring Teli original IP “Teli Core Technology” Achieved high integration with Teli’s original technology. Shorten the response time ! Teli Core Technology FPGA + All-in-one USB3 chip All-in-one Downsizing, All hardware processing with Register Setting CPU Mode Setting USB High Communication integration no CPU and Data Bus Image FPGA Data Bus Sensor Driving LINK IP PHY TG Data Bus Data Bus no Firmware ! TELI Core Technology Downsizing and super Register Setting FPGA high speed response ALU USB Communication /MUX by high integration Etc. Data Bus Data Bus Data Bus LINK IP Image PHY Sensor Driving TG Register Setting FPGA CPU USB Communication T ALU Te e l c i h C n o Data Bus /MUX Data Bus Data Bus ol r o Image Etc. LINK IP PHY Firmware process ge Downsizing, Hardware process y T Te e l c i h C n o Sensor Driving o TG l r oge y High Using conventional CPU core integration Access response (Average) PC (Board) side host controller : Intel / Renesas Corresponding Cameras; All models of BU / DU / DDU series Teli Core Geniric All-in-one Technology USB IP USB chip Command 100 times faster 10 times faster Overwhelming high speed processing ! Read register 2.2 / 5 μs 40.8 / 44.6 μs 223 / 546 μs Soware trigger (write register) 2.2 / 5.4 μs 46.9 / 71.0 μs 314 / 324 μs * Comparison value of read register access response with 'All-in-one USB chip' built-in model. TeliCamSDK Application Easy to capture image GEN<i>CAM available Varieties of functions for easy programming Python DNET *� C/C++ GenTL*�,*� Abundant sample code Package composition of TeliCamSDK TeliCamSDK Easy to understand manuals Driver Library Unified SDK for USB3, GigE & CXP Function setting Image capture Sample code Viewer Python library “pytelicam” *3 GenAPI,XML Image convert ImageJ plug-in “TeliPlugin” *4 Setting tools Instruction manual Register R/W Image storage * TeliCamSDK contains the components necessary for application development. System Enumeration Cameras Linux Windows Intel / AMD OS / Distribution *5 Ubuntu ARM USB� USB� CXP GigE 10 11 18.04 LTS 20.04 LTS 22.04 LTS amd64 amd64 amd64 Support ✓ ✓ ✓ ✓ ✓ ✓ TeliCamSDK for Linux supported ARM architectures. - Jetson nano / Raspberry pi 4 *6 *1: for Windows / *2: for USB and CXP / *3: Supports TeliCamSDK v4.0.0.1 or later / *4: Supports TeliCamSDK v4.0.1.1 or later / *5: Please contact us for other OS and distributions. / *6: Image might be missed depending on PC specifications. Peripheral I/O

Toshiba Teli USB3 Camera BU Series / DU Series / DDU Series Sequential Shutter mode + Bulk Trigger mode Output several images of dierent setting with one trigger pulse. Easy to capture the images for desirable inspection. Ext. Trigger in Corresponding Cameras; Camera settings BU040M series, BU132M, BU160M series, BU205M, BU238M series, BU302M series, BU406M series, BU505M series, BU1207M series, BU2409M series, Image output DU657M series, DU1207M series, DDU1207M series, DDU1607M series Setting 3 Setting 1 Camera Settings Setting 2 Setting 1 Memory Bank 1 Setting 2 Memory Bank 2 Get desirable image Save settings Setting 3 Load Memory Bank 3 any Setting Memory Bank 4 Memory Bank 3 Setting camera Memory Bank 1 conditions Memory Bank 15 Memory Bank 2 Bus Synchronization Fully synchronized exposure timing among several cameras.* Corresponding Cameras; Camera2 Camera3 BU040M series, BU160M series, BU205M, BU238M series, BU302M series, BU406M series, BU502M series, BU505M series, BU805M series, BU1207M series, BU1208M series, BU2409M series, DU657M series, DU1207M series, DDU1207M series, DDU1607M series, DDU2607M series Camera1 Camera4 Example; No cable needed for Stereo camera ‘Trigger in’ ! Motion capture Patent No. JP 5802727 B2 * The time stamp in the USB bus is used. The camera with same time stamp can synchronize. Event Notifications Camera notifies status informa- FrameTrigger - Reception of Frame FrameTransferStart - Start of transferring ExposureEnd - End of Exposure Start Trigger Streaming Data tion via event packet ! FrameTriggerError - Rejection of Frame FrameTransferEnd - End of transferring Start Trigger Streaming Data Timer0Start - Start of Timer ”0” FrameTriggerWait - Start of waiting for Frame Start Trigger ExposureStart - Start of Exposure Timer0End - End of Timer “0” Event notice without delay by the Teli Core Technology. Trigger input Rendering great service to vision systems with high speed as its Event notifications important feature. Detected signal Corresponding Cameras; BU series all models, Command DU series all models, DDU series all models Example of triaxial robot

Specifications MODEL*1 DU657M DU657MC DU1207MG DU1207MCG DDU1207MCG DDU1607MCG DU1207MCF DDU1207MG DDU1207MCF DDU1607MG DDU1607MCF DDU2607MG DDU2607MCG DDU2607MCF B/W or COLOR B/W COLOR B/W COLOR B/W COLOR B/W COLOR B/W COLOR Pixels 6.5M 12.3M 12.3M 16M 26.2M Imager model TELI Original 6.5M Sony IMX253 Sony IMX253 OnSemi XGS 16000 Gpixel GMAX0505 Imager size/type*2 1.1 type GS-CMOS 1.1 type GS-CMOS 1.1 type GS-CMOS 1.1 type GS-CMOS 1.1 type GS-CMOS Resolution 2,560 x 2,560 4,096 x 3,000 4,096 x 3,000 4,000 x 4,000 5,120 x 5,120 Frame rate 55 fps 32 fps 31 fps 62 fps 47 fps 28.4 fps Pixel size 5.0 x 5.0 μm 3.45 x 3.45 μm 3.45 x 3.45 μm 3.20 x 3.20 μm 2.50 x 2.50 μm Bus synchronization ✓ ✓ ✓ ✓ ✓ Bulk trigger ✓ ✓ ✓ ✓ ✓ Image buer 256MB 256MB 256MB 256MB 256MB Sequential shutter ✓ ✓ ✓ ✓ ✓ Short exposure mode*3 - ✓ - - - Product availability (CY) Available Available Available Available (Q1/2024) MODEL*1 BU040M BU040MCG BU160M BU160MCG BU040MG BU040MCF BU132M BU160MG BU160MCF BU205M BU238M BU238MC BU302MG BU302MCG BU238MCF BU302MCF B/W or COLOR B/W COLOR B/W B/W COLOR B/W B/W COLOR B/W COLOR Pixels 0.4M 1.3M 1.6M 2.2M 2.3M 3.1M Imager model Sony IMX287 e2v EV76C560 Sony IMX273 CMOSIS CMV2000 Sony IMX174 Sony IMX252 Imager size/type*2 1/2.9 type GS-CMOS 1/1.8 type GS-CMOS 1/2.9 type GS-CMOS 2/3 type GS-CMOS 1/1.2 type GS-CMOS 1/1.8 type GS-CMOS Resolution 720 x 540 1,280 x 1,024 1,440 x 1,080 2,048 x 1,088 1,920 x 1,200 2,048 x 1,536 Frame rate 523 fps 61 fps 240 fps 170 fps 165 fps 120 fps Pixel size 6.90 x 6.90 μm 5.3 x 5.3 μm 3.45 x 3.45 μm 5.5 x 5.5 μm 5.86 x 5.86 μm 3.45 x 3.45 μm Bus synchronization ✓ - ✓ ✓ ✓ ✓ Bulk trigger ✓ ✓ ✓ ✓ ✓ ✓ Image buer 256MB 256MB 256MB 256MB 256MB 256MB Sequential shutter ✓ ✓ ✓ ✓ ✓ ✓ Short exposure mode*3 ✓ - ✓ - - ✓ Product availability (CY) Available Available Available Available Available Available MODEL*1 BU406M BU406MC BU406MN BU406MCF BU502MG BU502MCF BU505MG BU505MCG 05MG BU805MCF BU1207MG BU1207MCG 208MCG BU505MCF BU8 BU1207MCF BU1208MG BU1 BU1208MCF B/W or COLOR B/W COLOR B/W COLOR B/W COLOR B/W COLOR B/W COLOR B/W COLOR Pixels 4.2M 5M 5M 8M 12.3M 12.3M Imager model CMOSIS CMV4000 Sony IMX547 Sony IMX250 Sony IMX546 Sony IMX253 Sony IMX546 Imager size/type*2 1.0 type GS-CMOS 2/3 type GS-CMOS 2/3 type GS-CMOS 2/3 type GS-CMOS 1.1 type GS-CMOS 1/1.1 type GS-CMOS Resolution 2,048 x 2,048 2,448 x 2,048 2,448 x 2,048 2,848 x 2,848 4,096 x 3,000 4,096 x 3,008 Frame rate 90 fps 75.6 fps 75 fps 46.7 fps 31 fps 30.8 fps Pixel size 5.5 x 5.5 μm 2.74 x 2.74 μm 3.45 x 3.45 μm 2.74 x 2.74 μm 3.45 x 3.45 μm 3.45 x 3.45 μm Bus synchronization ✓ ✓ ✓ ✓ ✓ ✓ Bulk trigger ✓ ✓ ✓ ✓ ✓ ✓ Image buer 256MB 256MB 256MB 256MB 256MB 256MB Sequential shutter ✓ ✓ ✓ ✓ ✓ ✓ Short exposure mode*3 - ✓ ✓ ✓ ✓ ✓ Product availability (CY) Available Available Available Available Available (Q1/2024) MODEL*1 BU2409MG BU2409MCG BU1203MC BU2409MCF BU602M BU602MC BU602MCF BU1203MCF BU2006MG BU2006MCF B/W or COLOR B/W COLOR B/W COLOR COLOR B/W COLOR Pixels 24.5M 6.2M 12M 20M Imager model Sony IMX540 Sony IMX178 Sony IMX226 Sony IMX183 Imager size/type*2 1.2 type GS-CMOS 1/1.8 type RS-CMOS 1/1.7 type RS-CMOS 1.0 type RS-CMOS Resolution 5,328 x 4,608 3,072 x 2,048 4,000 x 3,000 5,472 x 3,648 Frame rate 15 fps 60 fps 30 fps 19 fps Pixel size 2.74 x 2.74 μm 2.40 x 2.40 μm 1.85 x 1.85 μm 2.40 x 2.40 μm Bus synchronization ✓ - - - Bulk trigger ✓ ✓ - ✓ Image buer 256MB 256MB 256MB 256MB Sequential shutter ✓ - - - Short exposure mode*3 (Planning) - - - Product availability (CY) Available Available Available Available *1 : MODEL suix C/MC: without IR-cut filter, CF/MCF: with IR-cut filter, G/CG: with Dust-proof Glass *2 : Imager type GS-CMOS: Global shutter type CMOS sensor, RS-CMOS: Rolling shutter type CMOS sensor *3 : Short exposure mode The mode to switch it for short time exposure (approx. 1.1μs or more) by enhancing electronic shutter. (Contact for details) Before using this product, please read “Operation Manual“ carefully in order to use this product Notes on Safety afely and correctly. If this product should be used in the extraordinary conditions or environments, or if you have any questions or problems, please contact our sales division. https://www.toshiba-teli.co.jp/en/ teli camera Search The information of this catalog is subject to change without notice. Pregius logo, Pregius S logo and STARVIS logo are trademarks The information of this catalog is current as of November 2023. of Sony Corporation. Company name, product name or logo might be trademark or registered trademark of each company or organization. We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the user. 4000-0346-2311
