Page1
Pr oduct U.FL(A) Series
Pr esent a t i o n
Comparison with U.FL (Conventional Type),
U.FL(A) (Coa-Fit Type) and Competing Products
*Both Products
Mate with the
Same Receptacle
Features 1 2.1mm height(2.2mm Max.)
2 Excellent High Frequency Performance
(V.S.W.R)(Up to 18GHz)
DC to 3GHz :1.3 Max.
3 to 6GHz :1.4 Max.
6 to 9GHz :1.5 Max.
9 to 12GHz :1.6 Max.
12 to 15GHz : 1.7 Max.
15 to 18GHz : 2.0 Max.
3 Applicable Cable:
ø1.37mm (Single shield) (30 AWG)
ø1.13mm (Single shield) (32 AWG)
4 Self-alignment design enables stable mating
Patented
Confidential
Page2
U.FL(A) Series
Confidential Comparison Table
U.FL(Conventional Type) U.FL(A)
1.9 (2.0)
Mated Height (Max.) 〇 〇 2.1(2.2)
2.3-2.4 (2.4-2.5)
ø0.81/ø0.95/ø1.13/
Applicable Cable ◎ 〇 ø1.37, ø1.13
ø1.32/ø1.37
DC to 3GHz :1.3 Max.
3 to 6GHz :1.4 Max.
High Frequency Performance DC to 3GHz : 1.3Max. 6 to 9GHz :1.5 Max.
〇 ◎
(V.S.W.R) 3 to 6GHz : 1.4Max. 9 to 12GHz :1.6 Max.
12 to 15GHz : 1.7 Max.
15 to 18GHz : 2.0 Max.
Operating Temperature △ -40 to +90℃ ◎ -40 to +105℃
Insertion Sensation 〇 Good ◎ Excellent
Self-alignment × Poor ◎ Excellent
Assembly Steps △ 2 ◎ 1
Visibility of Cable
Assembly 〇 Good ◎ Excellent
Termination Area
Carrier Joint × Easy to Deform ◎ Hard to Deform
◎: Excellent 〇: Good △: Average ×: Poor
MKT-E-16039P_1_1 Issued: May. 14, 2021 © 2021 HIROSE ELECTRIC CO., LTD. All rights reserved. Subject to change without notice. Please contact Hirose representative for updated information. 2
Page3
U.FL(A) Series
High Frequency Performance
Confidential Comparison Data
ø1.37 Cable
Coa-Fit* (New one-step crimp termination) decreases cable assembly variation
Measuring Method *Cable Length=100mm
Reference Plane U.FL(A)-LP(P)-088(02)
APC 3.5
ø1.37 cable Port 2 Vector Network Analyzer
Port 1 Port 2
Double-ended
APC3.5 Measuring Adapter Test Board Receptacle
Cable Assembly Receptacle Test Board Measuring Adapter APC3.5
(male) HRM(G)-300-467B (FR-4) U.FL-R-SMT-1 U.FL-R-SMT-1 (FR-4) HRM(G)-300-467B
U.FL(A)-LP(P)-088 (male)
D.U.T.
Reference Plane
APC 3.5
Port 1 U.FL (Conventional)
INSERTION LOSS V.S.W.R. U.FL(A) [Coa-Fit]
*Coa-Fit is an FL plug that eliminates manual labor
and allows for complete automation.
MKT-E-16039P_1_1 Issued: May. 14, 2021 © 2021 HIROSE ELECTRIC CO., LTD. All rights reserved. Subject to change without notice. Please contact Hirose representative for updated information. 3
Page4
U.FL(A) Series
High Frequency Performance
Confidential Comparison Data
ø1.13 Cable
Coa-Fit* (New one-step crimp termination) decreases cable assembly variation
Measuring Method *Cable Length=100mm
Reference Plane U.FL(A)-LP(P)-088(02)
APC 3.5
ø1.13 cable Port 2 Vector Network Analyzer
Port 1 Port 2
Double-ended
APC3.5 Measuring Adapter Test Board Receptacle Test Board Measuring Adapter
Cable Assembly Receptacle APC3.5
(male) HRM(G)-300-467B (FR-4) U.FL-R-SMT-1 U.FL-R-SMT-1 (FR-4) HRM(G)-300-467B
U.FL(A)-LP(P)-088 (male)
D.U.T.
Reference Plane
APC 3.5
Port 1 U.FL (Conventional)
INSERTION LOSS V.S.W.R. U.FL(A) [Coa-Fit]
*Coa-Fit is an FL plug that eliminates manual labor
and allows for complete automation.
MKT-E-16039P_1_1 Issued: May. 14, 2021 © 2021 HIROSE ELECTRIC CO., LTD. All rights reserved. Subject to change without notice. Please contact Hirose representative for updated information. 4
Page5
U.FL(A) Series
High Frequency Performance
Confidential Comparison Data
ø1.37 Cable
Retains excellent high frequency performance in comparison with competitor’s crimp type
Measuring Method *Cable Length=100mm
Reference Plane U.FL(A)-LP(P)-088(02)
APC 3.5
ø1.37 cable Port 2 Vector Network Analyzer
Port 1 Port 2
Double-ended
APC3.5 Measuring Adapter Test Board Receptacle Receptacle Test Board Measuring Adapter
Cable Assembly APC3.5
(male) HRM(G)-300-467B (FR-4) U.FL-R-SMT-1 U.FL-R-SMT-1 (FR-4) HRM(G)-300-467B
U.FL(A)-LP(P)-088 (male)
D.U.T.
Reference Plane
APC 3.5
Port 1 Competing Product
INSERTION LOSS V.S.W.R. U.FL(A) [Coa-Fit]
*Coa-Fit is an FL plug that eliminates manual labor
and allows for complete automation.
MKT-E-16039P_1_1 Issued: May. 14, 2021 © 2021 HIROSE ELECTRIC CO., LTD. All rights reserved. Subject to change without notice. Please contact Hirose representative for updated information. 5
Page6
U.FL(A) Series
High Frequency Performance
Confidential Comparison Data
ø1.13 Cable
Retains excellent high frequency performance in comparison with competitor’s crimp type
Measuring Method *Cable Length=100mm
Reference Plane U.FL(A)-LP(P)-088(02)
APC 3.5
ø1.13 cable Port 2 Vector Network Analyzer
Port 1 Port 2
Double-ended
APC3.5 Measuring Adapter Test Board Receptacle Test board Measuring Adapter
Cable Assembly Receptacle APC3.5
(male) HRM(G)-300-467B (FR-4) U.FL-R-SMT-1 U.FL-R-SMT-1 (FR-4) HRM(G)-300-467B
U.FL(A)-LP(P)-088 (male)
D.U.T.
Reference Plane
APC 3.5
Port 1 Competing Product
INSERTION LOSS V.S.W.R. U.FL(A) [Coa-Fit]
*Coa-Fit is an FL plug that eliminates manual labor
and allows for complete automation.
MKT-E-16039P_1_1 Issued: May. 14, 2021 © 2021 HIROSE ELECTRIC CO., LTD. All rights reserved. Subject to change without notice. Please contact Hirose representative for updated information. 6
Page7
U.FL(A) Series
Mating Guide and
Confidential Self-Alignment Design
U.FL and NG
Competing Products
Misalignment
Results in
Increased Risk
Restricting the mating position of Damage
with round chamfering can
cause misalignment
Self-alignment Range±0.2mm
U.FL(A)
0.2
OK
Self-alignment Prevent Axis
Misalignment
Taper allows easy mating Uneven shell prevents misalignment
and realizes easy mating
Self-alignment of the plug enables stable mating.
MKT-E-16039P_1_1 Issued: May. 14, 2021 © 2021 HIROSE ELECTRIC CO., LTD. All rights reserved. Subject to change without notice. Please contact Hirose representative for updated information. 7
Page8
U.FL(A) Series
Confidential Single Action Mating
U.FL and
U.FL(A)
Competing Products
2 Action → 1 Action
Bend the shell Swage multiple barrel housing points Swage multiple barrel housing
points in single action
Simple Design Allows for Easy Tool Setting
MKT-E-16039P_1_1 Issued: May. 14, 2021 © 2021 HIROSE ELECTRIC CO., LTD. All rights reserved. Subject to change without notice. Please contact Hirose representative for updated information. 8
Page9
U.FL(A) Series
Confidential Visibility of Cable Terminated Area
U.FL and
U.FL(A)
Competing Products
Wiring Checkpoint Wiring Checkpoint
Shallowing the wiring checkpoint allows
increased visibility
MKT-E-16039P_1_1 Issued: May. 14, 2021 © 2021 HIROSE ELECTRIC CO., LTD. All rights reserved. Subject to change without notice. Please contact Hirose representative for updated information. 9
1.24mm
0.4mm
Page10
U.FL(A) Series
Confidential Carrier Deformation Prevention
Carrier deformation can occur prior to mating with the U.FL (conventional) type. By
increasing the carrier tabs from 1 to 2, deformation is prevented.
U.FL and
U.FL(A)
Competing Products
Carrier Tab 2 Carrier Tabs
Deformation
Example
Carrier tabs are difficult to deform, increasing reliability.
MKT-E-16039P_1_1 Issued: May. 14, 2021 © 2021 HIROSE ELECTRIC CO., LTD. All rights reserved. Subject to change without notice. Please contact Hirose representative for updated information. 10
