(Small Printer for Development) Printing Machine for R&D Applications

2024 Panasonic inkjet head/printer Catalog 【Small Printer for Development】 Printing Machine for R&D Applications Panasonic‘s “Small printer for development” has been developed for materials Development with inkjet technology, and also Panasonic provide an environment for device prototyping using inkjet technology. • Automatic circulation from small amounts of ink provides an efficient and stable verification environment. • It enables high-precision printing with a printing direction impact accuracy of 8 microns. • Panasonic inkjet heads, including those capable of ejecting high-viscosity ink is available, enabling validation to meet customer needs. 100 um Head and Jetting High-precision observation unit circulation Unit Observation image of flight status Inkjet Head SCAN Direction 100 um Enlarged view of the impact image SH Type DPN, D Type by the impact observation function with heater ( Features ) (1)Various Panasonic heads (For high definition, solvent resistance and high viscosity) can be mounted (2)Choice of 5 mL minimal-volume circulation and 50 mL small-volume circulation (3)Easily replaceable inkjet head and circulation unit (4)Drive Per Nozzle (DPN) technology enables high-precision volume adjustment (5)Standard flight observation unit to check discharge status (6)Standard landing observation function to observe landing conditions (7)Adjusting the pitch between print nozzles with head rotation (8)Equipped with an landing position correction function to ensure high-precision jetting. (9)Equipment technology for high positioning reproducibility

Printing Machine for R&D Applications Equipment Specifications Item Basic specifications ( for SH head ) Installed inkjet head Panasonic internal inkjet heads can be mounted 　　　*Select from the following mounted heads Compatible Ink Solvent ink, UV ink, high viscosity ink *Please inquire in advance.　 Number of compatible inks 1 color Supported head sizes ( for standard SH heads ) 1 pass with 1 head/1 ink 1 head Maximum print width: 67.564 mm Supported Work Size Maximum 200 mm × 200 mm * Customizable Printing resolution ( Scan direction, Nozzle direction ) Scan direction: 1 μm, Nozzle direction: adjustable by head rotation landing accuracy ±5 μm Printing Method One-way, multi-pass printing Alignment function Auto alignment function by recognition or manual teaching Discharge control Drive Per Nozzle ( DPN ) method ( in case of applicable head ) Ink supply system Circular system Ink heating system Compatible with circulating heaters and head heaters Print work feed system Stage drive Drawing data specification method Tiff file format/Drawn recipe format by in-house application Control method Print unit control: Built-in Windows PC Flight observation function Available Optional Features High-precision automatic circulation unit, N 2 environmental compliance, etc. Safety device Emergency stop button Device body size Width 790 mm × Depth 700 mm × Height 1,450 mm Equipment weight Printer body 170 kg Motion 100-220V 50/60 Hz, Vacuum ( for substrate adsorption ), Exhaust Duct ( for use of hazardous substances ) Pneumatic ( For automatic circulation unit, not required for very small volume unit ) Available heads Type SH S V2 ( in development ) Features ・For high definition ・For high definition ・For high viscosity discharge ・The head can be rotated and ・By single head horizontal placement ・The head can be rotated and the application pitch can be 600 dpi printing resolution achieved the application pitch can be changed arbitrarily changed arbitrarily Number of nozzles 1,600 nozzles 50 nozzles 400 nozzles ( 400 nozzles × 4 rows ) ( 25 nozzles × 2 rows, in-phase ) Printing resolution 150dpi ( Horizontal alignment ) 600 dpi ( Horizontal alignment ) 33.5 dpi ( Horizontal alignment ) Print width 67.5 mm ( Horizontal alignment ) 67.7 mm ( Horizontal alignment ) 18.1 mm ( Horizontal alignment ) Standard Droplet Volume 4 pL 4 pL 50 pL Ink Viscosity 5～20 mPa・s 5～20 mPa・s （ Recommendation ）10～100 mPa・s （ Max. ）～200 mPa・s Head interpolation heater Yes No No DPN control Yes Not possible Yes Example of use MicroLED ( Pixel devices ) Decoration, solar cells Adhesive application Options Item Specifications High-precision automatic circulation unit Volume: 50 ml, Minimum Circulation: 30 mL, Heating function: up to 60 degrees Celsius, with pressure control Impact substrate 200 mm square, with landing confirmation line pattern, special water-repellent finish for droplet location confirmation N 2 Environmental Response Detach the controls and install them outside the N 2 booth. Material durability test kit Small piece of wetted member for judgment of use of ink Safety Cautions ●Please read the User's Manual carefully to familiarize yourself with safe and effective usage procedures. ●To ensure safety when using this equipment, all work should be performed according to that as stated in the supplied Operating Instructions. Read your operating instruction manual thoroughly. Panasonic Group products are built with the environment in mind. For more information,please visit our website ▲ https://www.panasonic.com/jp/company/ppe/jigyo/inkjetprinter.html Inquiries… Panasonic Production Engineering Co., Ltd. Zip code 571-8502 2-7 Matsubacho, Kadoma,Osaka,Japan; TEL （: +81）6-6905-4882 mail : inkjet-sales@ml.jp.panasonic.com The contents of this catalog are as of September 1, 2024. Ver.September 1, 2024 © Panasonic Production Engineering Co.,Ltd. 2024 ●The color of the product is printed matter and may differ slightly from the actual color. ●The rating and design of the product are subject to change without notice for the purpose of improvement. ●This product is designed for use in Japan.Consult your dealer for overseas use. ●Be sure to read the instruction manual carefully before using the product.
