English PloViewAuto HPGL/Vector/Image File Converter

PloViewAuto Ver.11.0 - HPGL / Vector / Image Converter - PloViewAuto reads a lot of HPGL/Vector/Image files continuously, and converts it into format files often used, such as PDF, TIFF, DXF, and IGES, at high speed automatically. PloViewAuto will serve as tool greatly effective in systems configurations, such as electronic drawing warehouse and PDM. * Outline This program carries out continuation conversion of the file of format shown below. - Output 1 Input:HPGL,HP-GL/2,HP RTL,PDF,DXF,DWG,GERBER,NC-Drill, IGES,SXF,EMF,TIFF,JPEG,Bitmap,PCX,FPX,GIF,PNG Output:PDF,HP-GL/2,EMF,TIFF,DXF,DWG,JPEG,Bitmap,IGES, SXF, PCX,FPX,GIF,PNG,,CMT,HPGL/Printer - Output 2 Input :PDF Output:WMF, EMF, PS, EPS, SVG, XPS, HPGL, PCL Output mode has the two following modes. (1) Standby output mode The same input file as specified input file name with wild card is looked for, if it is, it will output, and input file is automatically deleted after output. When there is no input file , it waits until file comes. Flow of processing (2) Batch Output mode Plural input files described in specified output list file are outputted continuously. This program is the automatic output special edition version PloView (it is called Following PloView) and set. This program generates command line which starts the automatic output special edition version PloView, and has function to start PloView. Example of PDF output command line of PloView : PloView.exe /p abc.hgl abc.pdf If you use wildcards as input filenames, PloView reads multiple files. PloView.exe /p ab*.hgl ab.pdf * Operation conditions The personal computer of Intel compatible CPU Memory: 1GB or more Empty capacity of hard disk drive: 100MB or more Screen resolution: 1024 dots x 768 dots Above OS: Windows 7, 8, 10, 11 32Bit, 64Bit * Charge of a license 950 US$ / license All functions can be tried gratuitously for 30 days. PloViewAuto main dialog PloViewAuto set dialog PloViewAuto batch file creation dialog https://www.isoplotec.co.jp/
