2/3" 35mm 5MP Lens

33 M30.5*P0.5-6H 22.2 1-32UNF 32 2/3" F1.6/35MM/5MEGA/C-MOUNT FOCAL LENGTH f=35MM Focus adjust screw Iris adjust screw F.NO F=1:1.6~16 FOCUS DISTANCE 0.15M~1.5M FLANGE BACK 17.526MM IN AIR Image BACK FOCUS 12.52MM IN AIR FILTER SCREW SIZE M30.5*P0.5 MOUNT C REL.ILLUMINATION 6 CHIEF RAY ANGLE 5 SENSOR FIELD OF VIEW D H V TV DISTORTION <0.15% <0.1% WORKING OPTICAL DISTANCE MAGNIFICATION 2/3" FIELD OF VIEW MM D H V 900 0.038 232.7 147.53 4 800 0.043 207.87 155.9 750 0.045 195.45 146.59 (34.9--41.2) 17.526 700 0.048 183.03 137.27 650 0.052 170.61 127.96 600 0.056 158.19 118.64 550 0.061 145.77 109.33 500 0.066 133.35 100.01 450 0.073 120.92 90.963 400 0.082 108.5 81.375 350 0.092 96.072 72.054 300 0.106 83.641 62.731 250 0.124 71.206 53.404 WORKING TEPMERATRUE 200 0.151 58.762 44.071 STORAGE TEPMERATRUE 150 0.191 46.304 34.728 Common Tolerance 4 3 Model SBS-3516-5MP Angle 2 3RD ANGLE PROJN 0.000 1 Rev Description Name Date 0.00 Design Examine Checked Approved Unit mm 0.0 Scale 2:1 Ver 00 0 Date 2018.03.01 Date 2018.03.01 Date 2018.03.01 Date 2018.03.01
