光学式反射式ブルーエンコーダ　ワンチップIC　iC-PR

Page 1:EncoderBlue goes reflectiveFeaturess Lensless reflective opto-encoder iCs,compact, high-resolution, incrementals For reflective discs/scale of Ø 4, Ø 14, Ø 26 and Ø 43mm and 256μm grids Monolithic HD Phased Array with excellent signal matchings Integrated blue LED with power control, EncoderBlue®s Low-noise signal amplifiers with high EMI tolerances Pin-selectable modes of operation:Digital A/B/Z (x1, x2, x4, x8, x16 interpolated),analog COS/SIN with analog or digital Zs Index gating: Ungated (1T), B-gated (0.5T), AB-gated (0.25T)s Pin-selectable minimal edge distance: 80ns, 1μs, 10μss Complementary quadrature outputs PA, NA, PB and NBs Complementary index outputs PZ and NZs Analog signal output for ease of alignment and resolution enhancementby external interpolations Operating temperature range of –40°C to 105°Cs Compact and lensless optoQFN mold package (4mm x 4mm x 0.9mm)s Evaluation kits on requestDescriptionThe iC-PR series are advanced optical, reflective, lensless encoder iCsfeaturing integrated HD Phased Array photosensors and a blue LED. Theyprovide high signal quality with relaxed alignment tolerances.Differential digital ABZ outputs with or without interpolation or analogSIN/COS outputs with index are available. Typical applications areincremental encoders for motor control.Blue-enhanced photosensors are adapted to the short wavelength of theembedded blue LED, and provide low-jitter outputs due to improved signalcontrast. The unique assembly technology of the blue LED emitter andsensors results in low optical crosstalk.Applicationss Incremental encoderss Miniature motors and actuatorss X-Y and linear stagess Factory automation robotss Consumer robotsBlock DiagramiC-PRCONDITIONING CONVERSIONCONVERSIONOSCILLATOREVALUATIONPOWER-ONINDEX/DIGTRI-LEVELBLUE LEDCONTROLCONTROLDRIVERSSINE/DIGOUTPUTPOWERSIGNALDNCOSDPCOSSIN² COS²RESETLOGICDNSINDPSINMODETESTDPZDNZTM1GNDDSEL2TM2TMONZGNDAPAVZPBNAVCCSEL1TZVDDEDCPZNBANABYPDIG ---iC-PR Series

Page 2:Encoder iC-PR256 iC-PR0464 iC-PR1456 iC-PR2656 iC-PR2604 iC-PR4307Disc Size linear Ø 4mm Ø 14mm Ø 26mm Ø 26mm Ø 43mmOptical Radius - 1.625mm 4.65mm 10.475mm 10.475mm 19.223mmNative Resolution / CPR 256μm 64 250 256 250 256 360 720DX2 (x2 interpolation) 128μm 128 500 512 500 512 720 1440DX4 (x4 interpolation) 64μm 256 1000 1024 1000 1024 1440 2880DX8 (x8 interpolation) 32μm 512 2000 2048 2000 2048 2880 5760DX16 (x16 interpolation) 16μm 1024 4000 4096 4000 4096 5760 11520Reflective Opto EncodersThis preliminary information is not a guarantee of device characteristics or performance. All rights to technical changes reserved. · Rev. 2.0Am Kuemmerling 18 · D-55294 Bodenheim, Germany · Phone: 49 (6135) 9292-300 · Fax: 49 (6135) 9292-192 · www.ichaus.comDevice OverviewKey Specifications Pin Configuration oQFN24-4x4Pin FunctionsGeneralSupply Voltage VCC: 4.5V...5.5VVDD: 3.0V...5.5VSupply Current typ. 20 mAESD Susceptibility CDM, HBM (JEDEC)Operational Temperature –40°C to 105°CPackage (RoHS compliant) 24-pin optoQFN(4.0mm x 4.0mm, thickness 0.9mm)OutputsMax. Output Frequency 1.6MHz min.Saturation Voltage hi/lo 0.4V max. at /–4mAAB Duty Cycle Variation Mode DX1: /–5%Mode DX2, DX4, DX8, DX16: /–10%Digital Hysteresisof Interpolatortyp.5.6° (@ one cycle of sine/cosine)Analog Output Signal AAMP = single-ended ±250mVA250 = VCC/2 ±250mVA500DZ = VCC/2 ±500mVOperation ModesSEL 1 SEL 2 Mode Descriptionlow high DX1 digital A/B/Z (x1 interpolation)high low DX2 digital A/B/Z (x2 interpolation)low open DX4 digital A/B/Z (x4 interpolation)high high DX8 digital A/B/Z (x8 interpolation)high open DX16 digital A/B/Z (x16 interpolation)open low A250 analog COS/SIN/Zopen high AAMP analog COS/SIN/Zopen open A500DZ analog COS/SIN, digital Z (ungated)No. Name Function1 VDD 3.0V...5.5V Digital Supply Voltage2 SEL1 Mode Selection Input 13 SEL2 Mode Selection Input 24 TZ Index Gating Control Input5 PZ Index Output Z 6 NZ Index Output Z–13 EDC Edge Distance Control Input14 NB Incr. Output B–/Analog Sine–15 PB Incr. Output B /Analog Sine 16 NA Incr. Output A–/Analog Cos–17 PA Incr. Output A /Analog Cos 18 GNDD Digital Ground19 GNDA Analog Ground20 TMO Test Mode Output21 TM2 Test Mode Input 222 TM1 Test Mode Input 123 VZ Index Detection Control Input24 VCC 4.5V...5.5V Analog Supply Voltage7...12 n.c. not connected "$0%&1$0%&iC-PR Series
