防塵・防水丸形コネクタ比較表
スリオジャパンは過酷な環境または条件の悪い環境において、容易かつ確実な接続を実現するために、ありとあらゆるIP67、IP68の防水性、または、動的防水性IP69Kの、環境に優しい密封型の丸形コネクタを提供しています。フルプラスチック製/クイック差し込みシリーズから金属製/プッシュプルシリーズに至るまでの幅広い選択肢を備える、弊社の防水性コネクタ製品群は、埃、液体、水の侵入に対する保護が必要とされる状況下で安全な接続を提供します。
フルプラスチックのUTSまたはUTSXおよびClipperシリーズ, プラスチックボディに金属カップリングを持つUTGX, フルメタルのUTOおよび851シリーズ, パワーと信号のレイアウトが充実したUTLシリーズなどの仕様を比較検討していただけます。
このカタログについて
ドキュメント名 | 産業用丸形コネクタ比較表 |
---|---|
ドキュメント種別 | 製品カタログ |
ファイルサイズ | 1.1Mb |
登録カテゴリ | |
取り扱い企業 | スリオジャパン株式会社 (この企業の取り扱いカタログ一覧) |
この企業の関連カタログ
![](https://static.cluez.biz/common/img/base/loading.gif)
このカタログの内容
Page1
Souriau circular connectors
A powerful solution
for every application
Each application is unique with its own challenges. Souriau circular
connectors’ unparalleled resistance to harsh environments make
them the right solution. Waterproof and UV resistant, our connectors
are designed to maintain signal integrity and mechanical/electrical
functionality in mixed power and signal layouts.
Clipper UTS/UTSX UTGX UTO UTL 851
series series series series series series
Agriculture l l l l l l
Building automation
and control l l l l l
Data centers l l l
Energy l l l l l
Factory automation l l l l l l
Instrumentation l l l l l Reliable, durable circular connectors
Lighting l l l l
Mining, metals and for industrial applications
minerals l l l
Off-road l l l l l
Oil and gas l
Telecommunications l l l l l l
Utilities l
For more information contact us:
www.eaton.com/interconnect-support
© 2024 Eaton Eaton is a registered trademark.
All Rights Reserved
Document No. TF700-2A All other trademarks are property
January 2023 of their respective owners.
Page2
Souriau circular connectors Souriau circular connectors
CLIPPER series UTS/UTSX series UTGX series UTO series UTL series 851 series
Shell type Plastic Plastic Plastic + metal coupling Metal Plastic + metal latch Metal
Coupling type 180° screw coupling with positive audible safety latch 1/3-turn bayonet 1/3-turn bayonet 1/3-turn bayonet Push-Pull and audible click 1/3-turn bayonet
and audible click and audible click and audible click and audible click
Waterproof / IP rating IP67/68 IP68/69K IP68/69K IP68/69K IP68/69K IP67 mated (with appropriate backshells)
*with solder or O-ring contacts mated/unmated* mated/unmated* mated mated/unmated* IP68 (with cable gland)
Salt spray > 1,000 hours ≥ 500 hours ≥ 500 hours 48 hours - Nickel > 1,000 hours 48 hours - Cadmium, Nickel
96 hours - Black anodized 500 hours - Black anodized, Black Zinc Nickel
Unique attributes Plastic cost effective and robust UV resistant Lightweight plastic and EMI shielding (98 dB at 1 MHz) Key shape blind mate, UV resistant and High density layout (2 to 61 contacts)
robust metal coupling current breaking capacity Robust and corrosion resistant
Plating type No plating No plating No plating Black anodized or Nickel No plating Cadmium, Black anodized, Black Zinc Nickel, Nickel
(latch stainless steel)
Temperature range -40° C +125° C -40° C +105° C -40° C +105° C -40° C +105° C -40° C +105° C -55°C +125°C
Mating cycles 250 250 500 500 1,000 500
Number of shell sizes 4 sizes UTS: 5 sizes (8, 10, 12, 14, 18) 3 sizes 8 sizes 3 sizes 9 sizes
( 1, 2, 3, 4) [diameter 21 to 40 mm] UTSX: 3 sizes (10, 12, 14) (10, 12, 14) (10, 12,14, 16, 18, 20, 22, 24) (10, 12, 14) (8, 10, 12, 14, 16, 18, 20, 22, 24)
Number of layouts 8 layouts UTS: 36 layouts / UTSX: 24 layouts 24 layouts 27 layouts 4 layouts 38 layouts
Wire gauge 14 - 24 AWG 8 - 30 AWG 8 - 30 AWG 8 - 30 AWG 14 - 30 AWG 14 AWG and smaller
Contact size range #16, #20 #8, #12, #16, #20 #8, #12, #16, #20 #8, #12, #16, #20 #16, #20 #16, #20
Receptacle Square flange Square flange Square flange Square flange, Square flange, Square flange,
configurations and in-line receptacle jam nut and in-line jam nut and in-line jam nut jam nut and in-line jam nut and in-line
threaded receptacle threaded receptacle
Contact current rating Up to 13 AMPS Up to 44 AMPS Up to 44 AMPS Up to 44 AMPS Up to 16 AMPS Up to 13 AMPS
Contact termination Solder, crimp Solder, crimp, Solder, crimp, Solder, crimp, Crimp, screw, coax Solder, crimp, PCB straight
types PCB straight, screw, coax PCB straight, screw, coax PCB straight, coax
Contact types Stamped and formed, Stamped and formed, Stamped and formed, Stamped and formed, Stamped and formed, Machined
machined machined, coaxial and fiber optic machined, coaxial and fiber optic machined, coaxial and fiber optic machined, coaxial and fiber optic
Mixed power and No Yes Yes Yes Yes Yes
signal layouts
Flammability rating UL94 V0 UL94 V0 UL94 V0 UL94 V0 UL94 5VA UL 94 HB
(UL94 HB for sealed unmated version) (UL94 HB for sealed unmated version) (UL94 HB for sealed unmated version)
Ethernet compatible No Yes** Yes** Yes** Yes + DMX/DALI/RDM Yes**
**certain layouts
Environmental RoHS Yes Yes Yes Yes Yes Yes
Intermateable (1) Interchangeable with connectors type 5015 Souriau UTG, UTGX, UTO and UTP series Not intermatable, but interchangeable Souriau UTS, UTSX, UTX and UTP series None MIL DTL 26482 series 1
with Souriau UTS, UTSX, UTG and
UTO series
Note: (1): Product series are conditionally intermateable with same shell size/layout patern but IP, electrical and mechanical performances may be affected.
Eaton cannot guarantee or warranty product performance levels when mated or used in conjuncton with non-Souriau product.
