Page 1:Super High Purity BBO CrystalEco-friendlyThe outstanding quality of OXIDE’s proprietary BBO crystal enables thecontinuous operation over 3,000 hours at 1W and over 1,000 hours evenat 2W at Every Single Spot of the crystal.The small crystal deterioration leads to the output with a high beamquality and stable long-term operation.A proprietary, high-speed, precision Voice Coil Motor (VCM) servoactuator drives stable CW operation of the laser.Highly efficient wavelength conversion laser system results in anextremely low power consumption of less than 340 watts.BBO Crystalfrom 20mW up to 2W, the world’s highestCW 266nm DUV LaserSophisticated Servo Locking TechnologyDUV Beam ProfileChoice from 4 ModelsWe have four models of continuouswave, single frequency 266nmlasers covering a wide range ofoutput powers. These models aremarks on our history of continuousdevelopment of more than 18 years.Over 250 units of our laser productshave shipped all over the world intofields including-Semiconductor Inspection-Raman Spectroscopy-Photoluminescence-Fiber Bragg GratingFrequad-HPFrequad-MFrequadFrequad-COutput Power [mW]20 100 200 500 1000 2000Power Range0.7-2.0W0.3-1.0W100-200mW20-50mW
Page 2:1747-1 Makihara, Mukawa Hokuto, Yamanashi 408-0302 JapanTel 81-551-26-0022 Fax 81-551-26-0033sales@opt-oxide.com http://www.opt-oxide.comOXIDE CorporationContents are things of February 1, 2015Frequad-HPFQ50-20 / -10 / -07Frequad-MFQM-10 / -07 / -05 / -03FrequadFQ1200B / FQ1100BFrequad-CFQC-50 / -20OpticalWavelength 266 nm 266 nm 266 nm 266 nmOutput Power 2.0 / 1.0 / 0.7W 1.0 / 0.7 / 0.5 / 0.3W 200 / 100mW 50 / 20mWLinewidth < 0.005 pm < 0.005 pm < 0.005 pm < 0.005 pmPower Stability < ± 1 % /8 hrs < ± 1 % /8 hrs < ± 3 % /hr < ± 1 % /8 hrsExtinction Ratio > 100:1 > 100:1 > 100:1 > 100:1Beam Quality TEM00, M2 < 1.2 TEM00, M2 < 1.2 TEM00, M2 < 1.3 TEM00, M2 < 1.3Polarization Vertical, Linear Vertical, Linear Horizontal, Linear Vertical, LinearBeam Diameter 3 mm ± 0.3 mm 3 mm ± 0.3 mm 0.8 mm ± 0.2 mm 0.8 mm ± 0.2 mmDivergence (1/e2) < 0.2 mrad < 0.2 mrad < 0.4 mrad < 0.4 mradEllipticity ≥ 85 % ≥ 85 % ≥ 90 % ≥ 90 %GeneralPower Supply AC 100-240V 50/60Hz AC 100-240V 50/60Hz AC 100-240V 50/60Hz AC 100-240V 50/60HzPower Consumption < 300 W < 340 W < 260 W < 70 WCooling Air Water Air AirDimensions (Head) 240 x 840 x 160 mm 350 x 590 x 124 mm 419 x 480 x 165 mm 153 x 202 x 79 mmClass 4 laser products per IEC/EN 60825-1:2007Frequad-HP Frequad-M Frequad Frequad-CLong Lifetime0 200 400 600 800 1000 1200Output[W]0.01.02.0No Crystal ShiftSpecifications* Customization available upon requestTime [H]0 2000 4000 6000 8000 10000 12000Time [H]051015Output[mW]No Crystal Shift*APC mode*ACC mode
