産業用ＰＣ 『Ｎｕｖｉｓ－５３０６ＲＴ』 工場ライン等で必要な照明コントロールやカメラトリガ、エンコーダ入力、ＰＷＭ出力など様々なデバイス・機能を１台で統合管理します。高度な画像検査に対応可能です。

Machine Vision Nuvis-5306RT Series Intel® 6th-Gen Core™ i7/ i5 Vision Controller with Vision-Specific I/O, Real-time Control and GPU-Computing Key Features ‧ Intel® 6th-Gen Core™ i7/ i5 65W/ 35W CPU, up to 32 GB DDR4 ‧ Integrated vision-specific I/O - 4-CH CC/ CV lighting controller - 4-CH camera trigger outputs - 1-CH quadrature encoder input - 8-CH isolated DI and 8-CH isolated DO ‧ Patented MCU-based, real-time I/O control by DTIO* V2 and NuMCU ‧ Built-in camera interfaces - 4-CH IEEE 802.3at Gigabit PoE+ ports - 4-CH USB3.0 ports ‧ Supports NVIDIA® GPU with up to 75W TDP GPU-accelerated machine vision ‧ Patented graphic card ventilation* *R.O.C Patent No. I526834/ M534371 / M456527 Introduction As one of the most powerful vision controller ever created, Nuvis-5306RT integrates every single function you need for machine vision applications in a compact footprint, including exceptional computing power, built-in camera interfaces and real-time vision-specific I/O control. To ensure high quality images, a machine vision (MV) system requires accurate interaction between lighting, camera, actuator and sensor devices. Nuvis-5306RT integrates LED lighting controller, camera trigger, encoder input, PWM output and digital I/O, to connect and control all vision devices. All vision-specific I/Os are managed by Neousys’ patented MCU-based architecture and DTIO V2/ NuMCU firmware to guarantee microsecond-scale real- time I/O control. Computing power is another crucial requirement for a vision system. In addition to the remarkable performance brought by its Intel® 6th-Gen Core™ i7/ i5 CPU, Nuvis-5306RT can also accommodate 75W NVIDIA® GPU to leverage CPU-accelerated vision library or deep-learning vision software. Combining built-in PoE+ and USB3.0 interfaces and the expandability for CameraLink and CoaXPress, Nuvis-5306RT is the ideal platform for demanding MV applications. Specifications System Core Storage Interface Supports Intel® 6th-Gen Core™ LGA1151 CPU 2x internal SATA port for 2.5” HDD/SSD installation, - Intel® Core™ i7-6700 (8M Cache,3.4/ 4.0 GHz, 65W TDP) SATA HDD supporting RAID 0/1 Processor - Intel® Core™ i5-6500 (6M Cache, 3.2/ 3.6 GHz, 65W TDP) - Intel® Core™ i7-6700TE (8M Cache, 2.4/ 3.4 GHz, 35W TDP) mSATA 1x full-size mSATA port (mux with mini-PCIe) - Intel® Core™ i5-6500TE (6M Cache, 2.3/ 3.3 GHz, 35W TDP) Expansion Bus Chipset Intel® Q170 Platform Controller Hub 1x PCIe x16 slot @ Gen3, 8-lanes PCIe signals in Cassette, Graphics Integrated Intel® HD Graphics 530 PCI/PCI Express supporting ® Memory Up to 32 GB DDR4-2133 SDRAM by two SO-DIMM sockets - 75W NVIDIA GPU card - COTS CameraLink and CoaXPress camera interface card AMT Supports AMT 11.0 1x internal mini PCI Express socket with front-accessible SIM socket TPM Supports TPM 2.0 Mini PCI-E 1x internal mini PCI Express socket with internal SIM socket Vision-Specific I/O Interface (mux with mSATA) 4-CH LED lighting controller output , supporting Power Supply LED Lighting - Constant current mode DC Input 1x 3-pin pluggable terminal block for 8~35V DC input Controller (up to 2A per channel, 100 kHz dimming control) - Constant voltage mode (24V DC, 100 kHz dimming control) Remote Ctrl. & 1x 10-pin (2x5) wafer connector for remote on/off control and Status Output status LED output Camera Trigger 4-CH camera trigger output (12V DC output) Mechanical Encoder Input 1-CH quadrature encoder input (A/ B/ Z) Dimension 240 mm (W) x 225 mm (D) x 111 mm (H) Isolated 4-CH isolated high-speed DO Digital Output (<2 us transient time, for strobe/PWM) Weight 4.5 kg (incl. CPU, memory and HDD) 4-CH isolated high-current DO (up to 500 mA rated current) Mounting Wall-mount by mounting bracket Isolated Digital Input 8-CH isolated high-speed digital input (<2 us transient time) Environmental with i7-6700TE, i5-6500TE (35W TDP) Real-time Patented MCU-based real-time I/O control I/O Control with DTIO V2 or NuMCU firmware Operating -25°C ~ 60°C ** Temperature with i7-6700, i5-6500 (65W TDP) General I/O Interface -25°C ~ 60°C **/*** (configured as 35W CPU mode) -25°C ~ 50°C **/*** (configured as 65W CPU mode) Ethernet port 6x Gigabit Ethernet ports by Intel® 1x I219 and 5x I210 Storage PoE+ IEEE 802.3at PoE+ PSE on GigE Port 3 ~ Port 6, 80 W total power Temperature -40°C ~85°C** budget Humidity 10%~90% , non-condensing USB3.0 4x USB3.0 ports via native xHCI controller, 1000 MB/s total bandwidth Vibration Operating, 5 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) USB 2.0 4x USB2.0 ports Shock Operating, 50 Grms, Half-sine 11 ms duration Video Port 1x stacked VGA + DVI-D connector (w/ SSD, according to IEC60068-2-27)2x DisplayPort connectors, supporting 4K2K resolution EMC CE/ FCC Class A, according to EN 55022, EN55032 & EN 55024 Serial Port 2x software-programmable RS-232/422/485 port (COM1 & COM3) * For i7-6700 running at 65W mode, the high operating temperature shall be limited to 50°C and thermal throttling 1x RS-232 port (COM2) may occur when sustained full-loading applied. Users can configure CPU power in BIOS to obtain higher operating Audio 1x Mic-in and 1x Speaker-out temperature.** For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk (SSD) is required. All rights reserved. Copyright © 2018 Neousys Technology, Inc. www.neousys-tech.com

Nuvis-5306RT Series Appearance USB3.0 On/Off Ctrl & LED Indicators R e a l - t i m e Mic-in & DisplayPort x2 DVI Host x4 Status LED (HDD, WDT, IGN, PWR) SIM socket Vision I/O Speaker-out COM2 USB 2.0 Host x 4 8V~35V DC IN VGA Port GbE Port x2 PoE+ Port x4 PCIE x 1 COM1 & COM3 Dimensions Unit : mm 240 272 Ordering Information Model No. Product Description Nuvis-5306RT-DTIO Intel® 6th-Gen Core™ i vision controller with vision-specific I/O, real-time control by DTIO V2 and GPU-computing Nuvis-5306RT-NuMCU Intel® 6th-Gen Core™ i vision controller with vision-specific I/O, real-time control by NuMCU and GPU-computing Optional Accessories PA-160W-OW 160W AC/DC power adapter 20V/8A; 18AWGx4C/120cm, cord end terminals for terminal block, operating temperature : -30 to 70 °C. Fan-40 Fan assembly for 2-slot Cassette, 40x40x10 mm www.neousys-tech.com All specifications and photos are subject to change without prior notice 110. 5 125. 5 225
