「TPC6000-D152-T」は15"XGAモニタ採用の産業用ファンレス・パネル型コンピュータです。[CPU : Intel Celeron Bay Trail J1900]
■ カタログ記載内容
・仕様一覧
・サイズ・図面
・インターフェース
・製品ラインナップ
・オプション
このカタログについて
| ドキュメント名 | TPC6000-D152-T |
|---|---|
| ドキュメント種別 | 製品カタログ |
| ファイルサイズ | 1.6Mb |
| 登録カテゴリ | |
| 取り扱い企業 | 株式会社連基 (この企業の取り扱いカタログ一覧) |
この企業の関連カタログ
このカタログの内容
Page1
TPC6000-D152-T Industrial Panel PC
1 5 " XG A Fa n l e s s I n d u s t r i a l Pa n e l P C
I n t e l ® C e l e ro n ™ B a y Tr a i l J 1 9 0 0
Page2
TPC6000-D152-T
Specifications：
CPU Intel® Bay Trial J1900
Frequency Quad core 2GHz
L2 Cache 2MB
Processor
Chipset Intel Bay trail SOC
Memory 1 x 204-pin SODIMM DDR3L-1333MHz support up to 8GB
Storage Medium 1 x 2.5" SATA bay + 1 x mSATA
LAN 2 x Realteck RTL8111F 1000Mbps RJ-45 with surge protection,lightning protection design and 15KV ESD protection
Audio Realtek ACL662 Audio controller，built-in mono speaker(optional)
USB 1 x USB3.0/2.0/1.1, 3 x USB2.0/1.1
I/O
COM 1 x RS-232/485 (COM1), 5 x RS-232 (Optional 2xRS48,RS485 support automatic flow control）
Texpansion slot 1 x Mini-PCIe slot, extensible 3G,WIFI wireless card
Rear I/O VGA / HDMI / 2 x GLAN / 4 x USB / 6 x COM
Dimensions (W x H x D) 393mm x 317mm x 81mm (15.47" x 12.48" x3.19")
Physical Drill Hole Size (W x H) 376mm x 302mm (14.80" x 11.89")
NW -
OS OS Windows 7, Windows 7, Windows8, Windows10, Ubuntu
Input voltage DC 12V,support reverse polarity protection, +9~+30V (Option)
Power
Maximum Power Dissipation 38.6Watt
LCD Size 15" XGA TFT
Resolution 1024 x 768
Colors 16.7MB
Active Area (W x H) 304.13mm x 228.10mm (11.97" x 8.98")
Backlight LED
LCD
MTBF 30000hrs
Pixel Pitch(H x V) 0.297 x 0.297
Luminance 420cd/m2
Contrast Ratio 800 : 1
Viewing Angle (L) 80 / (R) 80 / (T) 80 / (B) 80
Type Resistive touch screen
Resolution 4096 x 4096
Transmittance > 75%
Controller interface USB
Touchscreen Driver Support Windows 7, Windows 8, Windows 10, Linux
Response Time < 5ms
Surface Hardness Mohs' Number 3H
Click life 250g / 35,000,000 times
Draw life 250g / 5,000,000 times
-20 ~ 60°C (-4~140℉ )(Wide temperature SSD)
Work Temperature
0 ~ 45°C (32~113℉ ) (General temperature HDD/SSD)
Storage Temperature -30 ~ 80℃ (-22 ~ 176℉ )
Relative humidity 5~95% (Non condensation)
Environmental
Shake SSD applied: 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
Shock SSD applied: 10 G, IEC 60068-2-64, Half-sine wave, 11ms duration
EMC CE/FCC Class A
Water-proof Front panel IP65
Industrial Panel PC
www.nodka.com
Page3
TPC6000-D152-T
Dimensions:
Unit：mm
Cabinet Drill Hole Size
I/O:
Interface Definition:
A:COM6 G:COM3
B:COM5 H:COM4
C:Power switch I:LAN*2
D:DC IN(12V) J:USB2.0*4
E:COM1 K:VGA
F:COM2 L:HDMI
Ordering Information:
Product Code Description
TPC6000-D152-T 15"LCD/Intel® Celeron™ Bay Trail J1900 quad-core Processor(2.0 GHz)/No Memory/No Hard Disk/6*RS-232(Optional 1*RS-232 or 485)/2 Gigabit Ethernet ports/4*USB2.0/Flat five-wire resistive touch screen/1024*768/DC12V input/Two-year warranty
Optional Equipment:
Option Adapter 12V/60W 2 pin Phoenix terminal
Option Chinese standard Power Line 1.8m
Standard Touch Pen
Standard 4*Hooks
Standard Manufacturer Certificate
Standard Warranty Card
Standard Random Listing
