Hybrid AOC(Active Optical Cable) Series

Hybrid AOC (Active Optical Cable) Series

Hybrid AOC(Active Optical Cable) Series HDMI 2.1 AOC HDMI 2.0 AOC DisplayPort 1.4 AOC DVI To DVI AOC (Digital video) Type-C to HDMI AOC HDMI A to D AOC (with a HDMI A/M to D/F Adapter) Type-C C/M TO C/M AOC (Audio/Video Only) Type-C C/M TO C/M AOC (Data Only) USB3.0 A/M TO A/F AOC

HDMI 2.1 AOC HDMI 2.1 AOC  High Speed Fiber Optics, Ultra HD (8K), Deep Color (48-bit) Supports 3D Displays  Bandwidth: 48Gbps Max. up to 56Gbps  Extend HDMI Up to 200m over Fiber Optics(MMF)  Cable OD: 4.8mm  Compliant to Link with all HDMI A-type Connector devices  Support 8k/4k/3D/1080p/1080i/720p Format  Support HDCP/EDID/CEC/DDC/Audio  Support Dynamic HDR  Highly resistant with EMI and RFI  Support HDMI Resolution up to 8K@60Hz, 4K@120Hz  Mass production in 2018 Q4 Certified  Certified  by ATC by CPR

HDMI 2.0 AOC HDMI 2.0 AOC  Compliant to link with all HDMI A-type connector devices  Bandwidth up to 18Gbps  Max length: 200m  Cable OD: 4.8mm  Support 4Kx2K@60Hz UHD/3D/1080p/1080i/720p format  Support HDCP/EDID/CEC/DDC/Audio  Thinner, lighter and softer than conventional copper cable  Highly resistant with EMI and RFI  No external power needed  Mass production in 2018 Q1 Certified  Certified  by ATC by CPR

DisplayPort 1.4 AOC DisplayPort 1.4 AOC  Compliant to link with all DisplayPort A-type connector devices  Bandwidth up to 32.4Gbps  Max length: 200m  Cable OD: 4.8mm  Support : 8K@60Hz, 4K@60Hz, Max to 4K@120Hz  Support Dynamic HDR  Highly resistant with EMI and RFI  No external power needed  Mass production in 2018 Q1

DVI TO DVI AOC (Digital video) DVI TO DVI AOC (Digital video)  DVI to DVI Single link  Max length: 200m  Cable OD: 4.8mm  No external power needed  Highly resistant with EMI and RFI  Supports hot plugging of DVI devices and resolutions up to 1080P  Mass production in 2018 Q4

Type-C to HDMI AOC Cable Type-C to HDMI AOC  Support HDR(High-Dynamic-Range) display  Support HDMI Max 4Kx2K@60Hz  Max length: 200m  Cable OD: 4.8mm  Highly resistant with EMI and RFI  Complies with DisplayPort 1.2 specification and is compatible with DP Alternate Mode on USB Type C Standard  Mass production in 2018 Q4

HDMI A to D AOC (with a HDMI A/M to D/F Adapter) HDMI A to D AOC (with a HDMI A/M to D/F Adapter)  Bandwidth up to 18Gbps  Max length: 200m  Cable OD: 4.8mm  Support 4K@60Hz, 3D/1080p/1080i/720p format  Support HDCP/EDID/CEC/DDC  Thinner, lighter and softer than conventional copper cable  Highly resistant with EMI and RFI  No external power needed  Mass production in 2018 Q4

Type-C C/M TO C/M AOC (Audio/Video Only) Type-C C/M TO C/M AOC (Audio/Video Only)  Compliant to link with all Type-C C/M Video interface devices  Compliant to DP 1.4 Bandwidth up to 8.1Gbps  Support : 8K@60Hz, 4K@60Hz, Max to 4K@120Hz  Highly resistant with EMI and RFI  Max length: 200m  Cable OD: 4.8mm  Overmold PVC, ABS, Zinc Alloy available  No external power needed  Mass production in 2018 Q4

Type-C C/M TO C/M AOC (Data Only) Type-C C/M TO C/M AOC (Data Only)  Compliant to link with all Type-C C/M data transmission devices  Bandwidth up to 10Gbps  Highly resistant with EMI and RFI  Max length: 200m  Cable OD: 4.4mm  Overmold PVC, ABS, Zinc Alloy available  No external power needed  The product is being tested

USB3.0 A/M TO A/F AOC USB3.0 A/M TO A/F AOC  Bandwidth up to 5Gbps  Support USB specification  Max length: 100m  Cable OD: 4.6mm  Highly resistant with EMI and RFI  Plug-n-play, no driver installation required  No external power needed  Mass production in 2018 Q4
