unichains(ユニチェイン)社製 モジュラーベルト式スキッドコンベヤ（横搬送）

平ベルトだとトラブル多いし・・・ 特 長 導入メリット ① モジュラーベルトは、スプロケットに ① 平ベルトと比べ、ベルトの蛇行、テン よるタイミング伝動なので、スリップ ション調整が激減！ 無し！ また同期運転も高精度！ ② スチールチェインと比べ、架台（搬送 ② モジュラーベルトは、硬質樹脂製な 物）の損傷がなくなった！ さらに給 ので架台（搬送物）にやさしい。 油作業もなくなった！ ③ おもちゃのブロック感覚でベルトを組 ③ トラブル時のダウンタイムが大幅に み立てでき、また部分交換も簡単で 短縮！ さらにベルトの長さの調整 す。 も自在なので在庫減、管理も楽だ！

ｽﾁｰﾙﾁｪｲﾝCV 平ﾍﾞﾙﾄCV ﾓｼﾞｭﾗｰﾍﾞﾙﾄCV メンテナンス性 △ × 〇 同期運転 〇 × 〇 長い搬送距離 〇 × 〇 張 力 〇 〇 △ 環境（煤・埃等） △ 〇 △ 補 修 × × 〇 寿 命 〇 × 〇 在庫管理 △ × 〇 【 用 途 】 【 導入実績 】 ■ 自動車 車体ライン ● 自動車産業 ■ 建設機械 車体ライン ● 建設機械産業 ■ 農業機械 車体ライン ● 農業機械産業 ■ パレット搬送ライン ● 物流産業 ● 各 製造業 【 unichains社製 スキッドコンベヤ用モジュラーベルトシリーズ 】 シリーズ名： uni CPB ・ uni CSB ・ uni XLB ベルトの選定及び、コンベヤの設計相談などもお気軽にお問い合わせください。 Ｕｎｉ ＴＫＳ株式会社（ユニテックス） お問い合わせ 〒４６０－０００２ 愛知県名古屋市中区丸の内１－５－２１玉泉ビル４階南 ＴＥＬ ： ０５２－２０９－２２３２ ＦＡＸ ： ０５２－２３１－１１０２ Ｅ－ＭＡＩＬ ： info@unitks.co.jp

Datasheet: uni XLB M2 C EN Plastic Modular Belt Series uni XLB Type M2 C Straight running belt Nominal pitch: 63.5 mm (2.50 in) P Surface type: Flat Surface opening: Closed Backflex radius: 100.0 mm (3.90 in) T L Pin diameter: 10.0 mm (0.39 in) ion irec t ing d n Run Belt mm in mm in material & color POM-NL K P (Nominal) 63.5 2.50 T 30.0 1.18 Pin and lock material & color PA6.6 N PP D L 15.0 0.59 - - - Non standard material and color: See uni Material and Color Overview. Alternative pin and lock systems and materials: Contact Customer Service. Permissible tensile force Belt weight Number of wear strips Belt width (Belt/pin material) (Belt/pin material) *Min. No. (Min. No.) drive POM-NL/PA6.6 POM-NL/SS POM-NL/PA6.6 POM-NL/SS sprocket **Carry **Return per shaft mm in N lbf N lbf kg/m lb/ft kg/m lb/ft (pcs) (pcs) 82*** 3.2 7560 1699 8400 1888 2.6 1.75 3.4 2.30 2 2 2 101 4.0 9045 2033 10050 2259 3.1 2.09 4.1 2.76 2 2 2 201 7.9 18054 4059 20060 4510 6.2 4.18 8.2 5.50 2 2 2 301 11.8 27063 6084 30070 6760 9.3 6.26 12.3 8.25 3 3 2 401 15.8 36072 8109 40080 9010 12.4 8.35 16.4 10.99 3 3 2 501 19.7 45082 10134 50091 11260 15.5 10.44 20.4 13.73 4 4 2 601 23.7 54091 12160 60101 13511 18.6 12.52 24.5 16.48 5 5 3 701 27.6 63100 14185 70111 15761 21.7 14.61 28.6 19.22 5 5 3 801 31.5 72109 16210 80121 18011 24.8 16.69 32.7 21.97 6 6 3 901 35.5 81118 18235 90131 20261 27.9 18.78 36.8 24.71 7 7 4 1001 39.4 90127 20261 100141 22512 31.0 20.86 40.9 27.46 7 7 4 1102 43.4 99136 22286 110151 24762 34.1 22.95 44.9 30.20 8 8 4 Additional standard belt widths are available in steps of 100.1 mm (3.94 in). Additional non-standard belt widths are available in steps of 33.4 mm (1.31 in). 1902 74.9 171180 38481 190200 42757 59.0 39.63 77.6 52.15 13 13 7 Additional standard belt widths are available in steps of 100.1 mm (3.94 in). Additional non-standard belt widths are available in steps of 33.4 mm (1.31 in). 2903 114.3 261270 58733 290300 65259 90.0 60.48 118.4 79.60 20 20 10 General belt tolerance is +0/-0.4% at 23°C/73°F and 50% RH. For exact belt width contact Customer Service. Non standard belt width on request. *Max. Load per Drive Sprocket. Belt material: POM-NL 12000 N (2698 lbf). **Max. Spacing between wear strips, Carry: 152.0 mm (6.00 in); Return: 304.0 mm (12.00 in). ***Type: uni XLB M1 C. = Single Link PITCH 63.5 MM/2.50 IN STRAIGHT RUNNING STANDARD

Datasheet: uni XLB M2 C Accessories Rubber Top / NON STANDARD A B Flat (M1) A B Flat A B Curved Belt Rubber A B Link Width Type Material & color Material & color mm in mm in size mm in 7.5 0.3 2.5 0.10 K318 81.1 3.19 Flat POM-NL K 05 K 7.5 0.3 2.5 0.10 K400 100.1 3.94 Curved Rib 14.0 0.58 4.6 0.18 K800 200.2 7.88 Other Non Standard Rubber profiles: See uni Rubber Profile Overview. Accessories Flight H 10% Curved R S T H 10% Curved Car Pusher Car Pusher H Width R S T Type Material & color Link size mm in mm in mm in mm in mm in K400 101.6 4.00 10% Curved POM-D UV Y 12.5 0.49 - - - - - - K800 199.6 7.86 Car Pusher POM-DK O 35.0 1.38 K800 199.6 7.86 18.1 0.71 32.0 1.26 9.0 0.35 Non Standard material and color: See uni Material and Color Overview.

Datasheet: uni XLB M2 C Sprocket Bore size mm in mm in mm in mm in mm in Z10 x 204.3 8.04 205.5 8.09 100.0 3.94 82.7 3.26 117.8 4.64 x x Z13 x 264.4 10.41 265.4 10.45 150.0 5.91 113.8 4.48 147.7 5.81 x x x Z15 x 306.0 12.05 305.4 12.02 150.0 5.91 134.4 5.29 167.7 6.60 x x Z20 x 408.0 16.06 406.0 15.98 360.0 14.07 185.5 7.30 218 8.58 x x Non standard material Molded sprocket Machined sprocket and color: See uni Material and Color Overview. B A Other sprocket sizes are available upon request. Two-part sprocket are available upon request. Round bores are always delivered with keyway. Other bore sizes are available upon request. uni Retainer Rings: See uni Retainer Ring data sheet Width of tooth = 16.0 mm (0.63 in) Width of sprocket = 33.0 mm (1.30 in) Max load per sprocket shown does not take bore size into account. Please also ensure that sufficient size shaft is chosen for corresponding load. For correct sprocket position: See uni Assembly Instructions for uni XLB. For more detailed sprocket information, contact Customer Service. No. of teeth Pilot Bore mm in 19.1 0.75 20.0 0.78 25.0 0.98 25.4 1.00 30.0 1.18 31.8 1.25 38.1 1.50 40.0 1.57 60.0 2.36 63.5 2.5 90.0 3.54 Overall diameter Pitch diameter Hub diameter Dimension A Dimension B Single row/Two way Double row/Two way Molded PA6 LG Machined PA6 N

Datasheet: uni XLB M2 C Expert advice, quality solutions Ammeraal Beltech Modular A/S and local service Hjulmagervej 21 for all your belting needs DK-7100 Vejle www.ammeraalbeltech.com T +45 7572 3100 This information is subject to alteration due to continuous development. Ammeraal Beltech will not be held liable for the incorrect F +45 7572 3348 use of the above stated information. This information replaces previous information. All activities performed and services rendered by admin@unichains.com Ammeraal Beltech are subject to general terms and conditions of sale and delivery, as applied by its operating companies. www.unichains.com Conveyor Belts Seamless Belts Modular Belts Timing Belts Transmission Belts Fabrication & service uni XLB M2 C/170523
